Description
| Model | T2S/ B2N | T2S/ BT2N |
| Power Supply | 7.4 kW | 22 KW |
| Input Voltage | AC230+15% | AC400+15% |
| Frequency | 50 Hz / 60 Hz | |
| Amperage | 6-32A | |
| Max. power Output | 7.4kW | 22kW |
| Net Weight | 9.3kg | |
| Dimension | 360 x 278 x 152 mm | |
| Charging Interface | IEC 62196-2 Compliant, Type 2 | |
| Safety Compliance | IEC 61851-1, IEC 61851-21-2 | |
| Multiple Protection | UUP,OUP,RCD (DC 6MA), SPD , Ground Fault Protection OCD, OTP, Control Pilot Fault Protection | |
| Operating Temprerature | -40C ~ 85C | |
| Relative Humidity | Up to 95% non-condensing | |
| Cable Length | 5m Standard Cable | |
| Warranty | 2 years | |
